Back axle strengthening

This is one in the category that I wouldn't have done to my car, were it not for the fact that a friend managed to break the back axle of his rally car at the end of this stage during the Deutschland Rally. And because he doesn't want to source and adapt a 4HA Jaguar based axle yet, we had a closer look at what had happened.
The problem was caused by a failure of the two puddle welds holding the right hand axle tube into the differential casing. Clearly the amount of torque available from a modified V8 together with the rough stages had been just that bit too much. So we needed a modification.

Searching through some old CCC articles on building a TR7V8 rally car, learned how to solve what is apparently the only weakness of the 5-speed back axle, i.e.: the fitting of the tubes into the differential casing. These tubes are normally pressed into the casings and welds are built up on the tubes through holes already in the casing. These welds are not intended to bond to the casing, but act as spigots or retaining pins. Unfortunately there are only two of these 'puddle' welds per side, and in this case the two on the right hand-side failed.

According to the people at CCC all that appears to be necessary to solve the problem is to increase the number of puddle welds to four per side. But we decide that we would go one stage further for the rally car, so we had a good look at the stiffening plate from a friend's Mk2 Escort back axle. And after some careful measuring on a spare axle and underneath the car, and a strength analyses we came up with this stiffening plate ...



At the time of writing the drawing file is away to a company to give us a quotation to get the plate laser-cut and the brackets machined. And after all the work I put in to get this far I don't see a point in not using one myself. So we will have a small batch made, depending on the price ...
